This is the maintenance schedule and service intervals for the BMW F 800 GS, BMW’s middleweight adventure motorcycle, made from model years 2008 through to 2017.
The BMW F 800 GS was first announced in 2007 for the 2008 model year, when it was introduced along with the new F 650 GS (with the same capacity detuned parallel twin motor, and other lower specs).
The original F800 GS was powered by a 798cc four-valve-per-cylinder DOHC parallel twin engine that made 63 kW (71 hp) @ 7,000 rpm, and maximum torque of 75 Nm at 4,500 rpm, relatively low.
The engine didn’t change significantly until the BMW F 800 GS was retired in 2020. Between 2008 and 2017, the maintenance schedule in the manual stayed the same, and all parts used (spark plugs, air filter, etc.) remained the same.
(The only change is that after the ride by wire update from 2016, you no longer have a throttle cable to lubricate. So if you have one, lube it. Otherwise, don’t!)
In mid May 2013, BMW also announced the F 800 GS Adventure, based on the same platform.
In late 2017, BMW updated its line, replacing the F 800 GS with the F 850 GS for the 2018 model year.
This site has links for things like oil and spark plugs from which we earn a commission (which unfortunately nobody can save, not even us). If you appreciate this work, then please use those links. Thanks!
What you need to service the BMW F 800 GS
Luckily, the parts needed to do a basic service on the BMW F 800 GS have remained the same across the years, as the engine wasn’t updated significantly from a maintenance perspective.
|Part||BMW F 800 GS part spec|
|Oil||BMW recommends using BMW Advantec Pro 15W-50, their own brand, but you can use other 15W-50 synthetic oils of high quality (API SJ/JASO MA2).|
|Oil filter||The standard oil filter is BMW part 11 42 8 409 567, which is equivalent to Hiflofiltro HF160RC.|
|Air filter||BMW part number 13 71 8 529 998, which is equivalent to Hiflofiltro HFA7913.|
|Spark plug||The standard spark plug is an NGK DCPR8E per the manual. BMW part number is 12 12 7 690 603.|
|Brake fluid||Use DOT 4 brake fluid, e.g. Castrol DOT 4, or you can get BMW part number 83 13 2 445 461 for the official stuff|
|Brake pads||Part numbers for the brake pads are 34 11 7 705 216 for the front brake pads (you need 2 pairs) and 34 21 7 722 884 for the rear.|
|Cable lubricant||Use Protect all cable life to lubricate moving cables.|
|General grease||Use a lithium soap-based grease for external pivot points like the kickstand etc.|
Maintenance schedule for the BMW F 800 GS
Below is the maintenance schedule for the BMW F 800 GS. It has been adapted to be a little easier to read and to fit this screen.
|km x 1000||0.5-1.2||10||20||30||40||50||60||70||80||90||100|
|mi x 1000||0.3-0.75||6||12||18||24||30||36||42||48||54||60||Every|
|BMW running-in check (including oil change)||X|
|Standard BMW service (see below)||Year|
|Engine oil change with filter||X||X||X||X||X||X||X||X||X||X||Year (a)|
|Check valve clearance||X||X||X||X||X|
|Replace all spark plugs||X||X|
|Replace air cleaner insert||X||X||X||X||X|
|Check or replace the air filter element||X||X||X||X||X||X||X||X||X||X||Year (b)|
|Telescopic fork oil change||X||X||X|
|Change brake fluid in entire system||Year, then 2 years (c)|
- a Annually or every 10,000 km (6,000 mi), whichever comes first
- b when used off road, annually or every 10,000 km (6,000 mi), whichever comes first
- c first after 1 year, then every 2 years
Standard scope of service — BMW F 800 GS
The standard annual list of service items is below.
- [D] means items that a dealer does.
- [CT] is for models with a cable throttle, before the Ride by Wire update in 2016. Other maintenance items are 100% identical.
|Standard scope of service — BMW F 800 GS|
|[D] Performing the brief test using the BMW Motorrad diagnostic system|
|Check coolant level|
|Check/adjust clutch play|
|[CT] Check accelerator Bowden cable for ease of movement, chafing and kinks, and play|
|Check the front/rear brake fluid level|
|Check the front/rear brake pads and brake discs for wear|
|Visually inspect the brake lines, brake hoses, and connections|
|Check tension of spokes and tighten as needed|
|Check the tire pressure and tread depth|
|Check and lubricate the chain drive|
|Check side stand for ease of movement|
|Check centre stand for ease of movement (when fitted)|
|Check the lighting and signal system|
|Check the steering-head bearing|
|Check the engine start suppression works|
|Final inspection and road safety check|
|[D] Set the service date and remaining distance to service|
|Check charging state of battery|
|[D] Confirm the BMW service in the vehicle literature|
About the BMW F 800 GS
The BMW F 800 GS was an all-new model when it was launched in 2007 for the 2008 model year.
Before the F 800 GS, the small adventure bikes that BMW offered (along with the R 1200 GS of the time) were single-cylinder 650cc thumpers. BMW continued to offer these for a while in the form of the BMW G 650 GS, but that line has now been retired.
But the BMW F 800 GS had an uncommon engine style for BMW — the parallel twin. BMW used a 798cc dual overhead-cam liquid-cooled parallel twin for both its F 800 GS and F 650 GS twin, though in different states of tune. The F 650 GS was also generally lower spec in brakes, suspension, and some other components.
An unusual characteristic of the F 800 GS’ parallel twin engine is the firing order. It has a 360 degree crank, which means one firing cycle for each crankshaft rotation. The pistons move up and down together. This means the sound is just like that of boxer engines, which have the same firing offset.
BMW claims it gives the engine excellent torque characteristics, but similar claims are made of engines with other firing orders by other manufacturers (e.g. Yamaha claims the same for the Ténéré 700 with its 270-450 firing order).
The pistons moving together leads to some vibration, which is smoothed out using a balance shaft. Despite this, the F 800 GS is still a vibey-bike — something to be expected. All BMW adventure bikes share this characteristic.
As you’d expect from an adventure bike, the BMW F 800 GS has ample suspension travel. The front forks (which are conventional forks, not Telelever like on the R 1200 GS) give you 230mm of travel.
The wheels are spoked, and the tyres are Continental Twinduro (in standard trip) which are capable on a variety of terrain types. Brakes are Brembo, with optional and later standard ABS.
There were some updates for the BMW F 800 GS:
- 2008-2012: The original 798cc parallel twin F 800 GS with optional ABS.
- 2013 – 2016: Updated engine, still a 798cc parallel twin, with slightly more power and torque (higher in the rev range). Added an updated display, optional ASC and ESA, and standard ABS in both models, as well as cosmetic changes. BMW introduced the BMW F 800 GS Adventure in 2014.
- 2017 – 2020: Same engine, but now with ride by wire with ride modes, updated silencer, new instrument panel, and other minor updates including Euro 4 emissions compliance.
Even though the F 800 GS got nicer looking and more high-tech over time, the engine stayed mostly the same, and so did maintenance.
The only aspect of maintenance to change over the F 800 GS’ lifetime is that with ride by wire (in 2017), you no longer have to check and lubricate a throttle cable as part of regular maintenance.
Tyres for the BMW F 800 GS
The BMW F 800 GS ships standard with the following tyre sizes and pressures.
|Wheel||Tyre size||Tyre pressure (cold)|
|Front||90/90-21||2.2-2.5 bar (one-up to 2-up/with luggage)|
|Rear||150/70-17||2.5-2.9 bar (one-up to 2-up/with luggage)|
Manual for the BMW F 800 GS
The maintenance schedule for the BMW F 800 GS came from the user’s manual. We used a few from different years and compared them. You can see screenshots below.
You can download the user manuals directly from BMW’s website here.
